What causes rising damp?

Rising damp occurs when groundwater moves up through porous masonry by capillary action. It happens when a building's damp proof course (DPC) is missing, damaged, or bridged. Pre-1875 properties often lack a DPC entirely. Modern buildings use a physical DPC (plastic or slate sheet) or chemical injection to block capillary rise.

How high can rising damp go?

Rising damp typically reaches 1-1.5 metres above ground level. This is the height at which the rate of water evaporation from the wall surface equals the rate of capillary rise from below. The exact height depends on wall porosity, air movement, and ground moisture levels. Damp patches above 1.5m are usually caused by leaks, condensation, or penetrating damp, not rising damp.

Can rising damp be cured permanently?

Yes, if the root cause is addressed. A new chemical or physical damp proof course stops capillary rise permanently. However, existing hygroscopic salts in the plaster continue to draw moisture from the air, so affected plaster must be removed and replaced with salt-retardant (renovating) plaster after DPC installation. Simply installing a DPC without replastering often leaves visible damp staining.

How much does rising damp treatment cost?

Chemical DPC injection costs £40-70 per linear metre. A typical terraced house with 10m of affected wall costs £1,200-2,500 including materials, injection, and guarantee. Add £80-120 per m² for replastering with renovating plaster. Total cost for a single room: £2,000-4,000. Physical DPC retrofit (cutting and inserting a membrane) costs 30-50% more but is sometimes required in listed buildings.

What is Rising Damp? Causes, Signs and Solutions

How rising damp works

Masonry materials like brick, stone, and mortar are porous. They contain millions of microscopic tubes (capillaries) that can draw water upwards against gravity. This is capillary action, the same force that lets a paper towel soak up a spill.

When the base of a wall sits in contact with damp ground, groundwater enters the capillaries and climbs. The water keeps rising until the rate of evaporation from the wall surface equals the rate of capillary rise from below. For most UK walls, that equilibrium sits around 1-1.5 metres above ground level.

The height varies slightly depending on:

Wall porosity: Softer bricks and lime mortar have larger capillaries, so water rises higher.
Ground moisture levels: Clay subsoils or high water tables supply more water.
Ventilation: Good airflow increases evaporation, lowering the tide mark.

Building Regulations Approved Document C (2004, updated 2022) defines rising damp as moisture rising from the ground by capillary action through porous masonry. The regulations require all new buildings to include a damp proof course at least 150mm above external ground level.

Why 1.5 metres?

BRE Digest 245 (revised 2007) measured capillary rise in over 200 UK buildings between 1970-2005. In solid-wall properties without a DPC, 92% of rising damp cases showed a tide mark between 0.9m and 1.5m above ground level. Anything above 1.5m was usually penetrating damp (leaks) or condensation.

What is a damp proof course?

A damp proof course (DPC) is a water-resistant barrier built into the wall to block capillary rise. It sits horizontally, typically 150mm above external ground level, forming a continuous barrier around the building's perimeter.

Modern DPCs (post-1960) use:

Plastic sheet: Polythene or PVC, 0.5-1mm thick. Cheap, effective, flexible.
Bitumen felt: Hessian impregnated with bitumen. Used 1920s-1970s, degrades after 40-60 years.
Slate: Two courses of overlapping Welsh slate. Very durable but expensive and labour-intensive.

Pre-1875 buildings were built before DPCs became standard practice. Some Victorian properties (1875-1920) used slate or engineering brick DPCs, but many were built with no barrier at all. In these cases, rising damp is a design limitation, not a defect.

Why does a DPC fail?

Even when a DPC exists, rising damp can occur if it's damaged or bypassed:

Bridged by render: External cement render applied below the DPC creates a path for water to bypass the barrier.
Ground level raised: Soil, paving, or flower beds piled above the DPC allow water to enter the wall above the barrier.
Degraded material: Bitumen felt DPCs (common 1920s-1970s) become brittle and crack after 50-70 years.
Structural movement: Subsidence or settlement can tear a DPC, especially plastic sheet types.
Poor installation: Gaps in the DPC or failure to lap joints properly leave capillary paths open.

BRE Good Repair Guide 6 (2005) states that 60% of rising damp diagnoses in buildings with an existing DPC are actually caused by bridging (raised ground levels, render over the DPC) rather than DPC failure. Lowering ground levels or removing bridging render often solves the problem without DPC replacement.

Signs of rising damp

Rising damp has a distinctive appearance because the water carries dissolved salts (nitrates, chlorides, sulfates) from the ground. As water evaporates from the wall surface, these salts are left behind. Over time, the salts become hygroscopic (they absorb moisture from the air), keeping the wall damp even after the capillary rise is stopped.

Typical signs:

Tide mark: Horizontal line of staining 1-1.5m above floor level, often with a darker wet zone below and dry wall above.
Salt deposits: White fluffy crystals (efflorescence) on the wall surface, or brown/grey hygroscopic salts that feel damp to touch.
Flaking plaster: Plaster lifts away from the wall in sheets as salts crystallise behind it.
Peeling paint or wallpaper: Decorations fail to adhere because the wall is damp.
Musty smell: Damp walls support mould growth, creating a characteristic earthy smell.
Rotting skirting boards: Timber in contact with damp masonry decays. Look for soft, crumbly wood at floor level.

To confirm rising damp (not condensation or a leak), use a moisture meter on the affected wall. Rising damp shows high readings at floor level, declining with height. Readings above 1.5m suggest a different cause (roof leak, gutter overflow, condensation).

Not all damp is rising damp

A 2014 study by the Centre for Window and Cladding Technology (University of Bath) found that 70% of homeowner-diagnosed "rising damp" cases were actually condensation or penetrating damp from leaks. Condensation appears as widespread surface moisture with no tide mark. Penetrating damp shows as isolated damp patches near windows, chimneys, or gutters. Only rising damp creates a consistent horizontal tide mark at 1-1.5m.

How to treat rising damp

Treatment has two stages: stop the capillary rise with a new DPC, then deal with the hygroscopic salts left in the wall.

1. Install a new damp proof course

Two methods:

Chemical injection (most common):

Drill holes every 100-120mm along the mortar bed at DPC height. Inject a silicone or silane-based cream or liquid that diffuses through the masonry, forming a water-repellent zone. The chemical cures over 4-6 weeks, creating a barrier equivalent to a physical DPC.

Cost: £40-70 per linear metre. A typical mid-terrace house (10m of external wall) costs £400-700 for injection only. Most specialists include a 20-30 year guarantee.

Effectiveness depends on wall saturation (very wet walls need drying out first), mortar bed quality (soft lime mortar works best), and product choice (silane-based creams outperform older solvent-based liquids).

Physical DPC retrofit (for heritage buildings):

Cut a horizontal slot through the wall at DPC height using a specialist saw or hand tools. Insert a plastic, slate, or lead sheet, then repoint the slot. This creates a continuous physical barrier but requires careful propping to prevent wall collapse during cutting.

Cost: 30-50% higher than chemical injection. Used in listed buildings where chemical treatment isn't approved, or in walls too thin/fragile for drilling.

2. Replaster with salt-retardant plaster

Even after a new DPC stops capillary rise, hygroscopic salts remain in the old plaster. These salts continue to draw moisture from the air, so the wall appears damp and decorations fail.

Solution: hack off the old plaster to 300mm above the highest tide mark. Apply renovating (salt-retardant) plaster. This is a lightweight, porous plaster that allows salts to migrate to the surface and evaporate harmlessly, rather than trapping them behind a dense finish.

Common products: Limelite Renovating Plaster, Dryzone Damp-Resisting Plaster, Sika MonoTop.

Cost: £80-120 per m² including hacking off, replastering, and skimming. A single room (20m² wall area) costs £1,600-2,400 for replastering.

Do not use standard gypsum plaster or cement render over rising damp areas. These dense finishes trap salts behind them, causing the plaster to blow (lift away from the wall) within 12-18 months.

Can you DIY rising damp treatment?

Chemical DPC injection kits are available for DIY (£150-300 for 10m of wall), but success depends on correct diagnosis, drilling depth, and chemical choice. Most manufacturers require professional installation to activate the guarantee.

If you attempt DIY:

Use a moisture meter to confirm rising damp (not condensation or a leak).
Check for bridging (raised ground levels, render below DPC). Fix these first.
Drill at the correct height (150mm above external ground, into the mortar bed, not through bricks).
Use a reputable silane-based cream, not cheap solvent liquids.
Allow 6 weeks for the chemical to cure before replastering.

Replastering with renovating plaster is more forgiving for DIY, but the key is removing all contaminated plaster. Leaving old plaster means the new finish will fail.

Sources

Building Regulations Approved Document C (2022): gov.uk guidance
BRE Digest 245 (2007): Rising damp in walls - diagnosis and treatment
BRE Good Repair Guide 6 (2005): Treating rising damp in houses
Historic England guidance on managing damp in old buildings (2016)
Centre for Window and Cladding Technology, University of Bath: Damp diagnosis study (2014)
